Front view of Nicolas Correa Prisma 20 machine

Thank you for your visit

This machine was recently sold. Take a look at similar options or get in touch with us directly.

Browse all similar machines

Browse similar machines

Nicolas Correa Prisma 20

Photo Gallery

Nicolas Correa - Prisma 20ES-MIL-NIC-2004-00001

Sold

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
Nicolas Correa Prisma 20 Milling machine

Show in original language

This Nicolas Correa Prisma 20 Milling machine was manufactured in the year 2004. It is equipped with a Heidenhain iTNC 530 control unit and has 4 axis. The machine has a spindle speed of 550-4000 rpm.

Overview

brand: Nicolas Correa
year: 2004
MODEL: Prisma 20
application type: Milling
Location: Spain
machine type: CNC Milling Machine
control unit brand: HEIDENHAIN

Technical Information - Nicolas Correa Prisma 20

General Data

Machine weight: 14000 kg

Control Unit

Model: iTNC 530
Brand: HEIDENHAIN

Main drive

Number of spindles: 1
Spindle speed range: 550-4000 1/MIN

Movement

X-AXIS Movement: 2000 mm
Y-AXIS Movement: 1000 mm
Z-AXIS Movement: 1000 mm

Workpiece

Workpiece weight: 3500 kg

Table

Outer length: 2000 mm
Outer width: 900 mm
Number of tslots: 5
Distance between: 200 mm

Tools

Type of tool holder: ISO-50

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
