Mazak - Integrex 100 IV STIT-TUR-MAZ-2011-00001

Name: Mazak Integrex 100 IV ST
Brand: Mazak
SKU: IT-TUR-MAZ-2011-00001
Price: 90000 EUR
Availability: InStock

90,000 €

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Download PDF

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used Mazak Integrex 100 IV ST For Sale | gindumac.com

Show in original language

This 5-axis Mazak Integrex 100 IV ST was manufactured in 2011. It features a main spindle with a 6" hydraulic chuck, 4,000 rpm max speed, and 30 kW power. The second spindle matches these capabilities. Its milling spindle can reach up to 20,000 rpm. Includes a high-speed ATC with a 20-tool capacity, expandable to 120. Ideal for single-setup machining with its heavy-duty construction and MAZATROL MATRIX CNC control. Contact us for more information about this machine.

Overview

brand: Mazak
year: 2011
MODEL: Integrex 100 IV ST
application type: Turning
Location: Italy
machine type: Turn-Mill Centre
control unit brand: MAZATROL

Technical Information - Mazak Integrex 100 IV ST

Control Unit

Brand: MAZATROL
Model: Matrix

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Chuck type: 6" hydraulic chuck with bar capacity max /spindle speed: 4000 rpm max /power: 30 kw / 22 kw continuous/ max torque: 500 nm /spindle nose: a2-8/ acceleration time: 5. 1 seconds
- - Type: 6" hydraulic chuck max speed: 4000 rpm max power: 26 kw / 22 kw continuous /max torque: 724 nm /spindle nose: a2-8 /acceleration time: 2. 7 seconds
- - Max speed: up to 20000 rpm (optional) /max power: 18. 5 kw/ max torque: 119 nm/ taper type: km63, capto c6, bt40
- - X-axis: 410 mm/ y-axis: ±70 mm (total 140 mm) /z-axis: 805 mm/ b-axis (milling head): 210° rotation/ c-axis (spindle): 0. 0001° resolution (full contouring)
- - Max turning diameter: approx. ø545 mm/ max turning length: approx. 600 mm
- - Tool capacity: 20 tools standard, expandable to 120 /changer type: high-speed cam-driven system
- - Heavy-duty construction with linear guides “done in one” multi-tasking concept for single-setup machining/ cnc control: mazatrol matrix with 3d simulation/ intelligent thermal shield for automatic thermal compensation
Qualitative Machine Benefits:
- - There are 2 units available

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
