Front view of KOVOSVIT MAS SP 430 Y/L2 machine

Thank you for your visit

This machine was recently sold. Take a look at similar options or get in touch with us directly.

Browse all similar machines

Browse similar machines

KOVOSVIT MAS SP 430 Y/L2

Photo Gallery

KOVOSVIT MAS - SP 430 Y/L2RU-TUR-KOV-2016-00001

Sold

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
KOVOSVIT MAS SP 430 Y/L2 Turning

Show in original language

This KOVOSVIT MAS SP 430 Y/L2 Lathe was built in the year 2016. This 8 axis machine can operate with a spindle speed up to 3150 rpm. It includes a bar coolant system, an air conditioning of the electrical cabinet, a machine status signaling and travel packages accessories.

Overview

brand: KOVOSVIT MAS
year: 2016
MODEL: SP 430 Y/L2
application type: Turning
Location: Russia
machine type: Horizontal Turning Machine

Technical Information - KOVOSVIT MAS SP 430 Y/L2

General Data

Machine weight: 12500 kg

Main drive

Spindle speed range: 3150 1/MIN
Number of axis: 8

Additional Equipment

- Coolant system
- Air conditioning of the electrical cabinet
- Machine status signaling
- Chip gun
- Travel packing
- Travel packaging accessories
- Upper tool head
- Steady rest SLU 4 (Range 30-245)
- Programmable tailstock

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Machine dimensions: 5591 x 2594 x 20402 mm
- - Clamping force range: 4-24 kn
- - Quill stroke: 160 mm
- - Quill diameter: 150 mm
- - Max. Tool spindle speed: 4000 min
- - Cutter size: 32 x 25 mm
- - Max. Workpiece diameter: 680 mm
- - Max. Turning diameter over cross supersport: 480 mm
- - Max. Diameter of processing from the upper head: 550 mm
- - Max. Spindle passage: 90 mm
Qualitative Machine Benefits:
- - Clamping force range: 4-24 kn
- - Max. Feed force: 17 kn

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
