HAITIAN - MARS MA10000 IICH-INJ-HAI-2016-00001

Additional Information

Machine Benefits

• Technical Machine Benefits:
  • - Screw diameters: a: 90 mm b: 100 mm c: 110 mm d: 120 mm
  • - Calculated injection volumes: a: 2990 cm³ b: 3691 cm³ c: 4467 cm³ d: 5318 cm³
  • - Injection capacities (ps): a: 2721 g b: 3359 g c: 4085 g d: 4838 g
  • - Injection speed rates: a: 544 g/s b: 671 g/s c: 812 g/s d: 967 g/s
  • - Injection stroke: 470 mm / injection stroke: 470 mm / heating input power: 84 kw
  • - Clamping force: 10000 kn / space between tie-bars (hxv): 1160x1160 mm
  • - Die height available: max: 1160 mm/ min: 500 mm
  • - Motor opening stroke: 1220 mm
  • - Dimensions of machine (lxwxh): 12. 3 x 2. 92 x 3. 75 m / weight (kg): 50500 kg

Payment Terms

• Payment in advance

• Asset Financing
